TTP-345

Thermal Transfer Desktop Barcode Printer Model TTP 345

Name: Thermal Transfer Desktop Barcode Printer Model TTP 345
SKU: KFT-TTP-345
Price: 29000 INR

₹29,000

Desktop thermal-transfer barcode label printer. Narrative lists 177.8 mm/s, 203 dpi and four-inch printing; table lists 300 dpi, selectable 2–5 ips and 106 mm maximum print width. Table also claims 1500 labels/min without pitch/test basis. USB2.0, serial and parallel interfaces, TSPL-EZ/TPLE/TPLZ language support and optional use with LRW-100 are described. Hardware configuration needs confirmation.

Confirm configuration, availability and commercial terms with our team.

Specifications

Media Width	20 – 112 mm (0.78” – 4.4”)
Media Thickness	0.06 – 0.19 mm (2.3 – 7.4 mil), max 150 g/m2
Media Core Diameter	25.4 – 76.2 mm (1” – 3”)
Label Length	Min. 10 mm (0.4”)
Resolution	300 dpi
Print Speed	2, 3, 4, 5 ips selectable
Maximum Print Width	106 mm (4.17”)
Maximum Print Length	1,016 mm (40”)
Ribbon Capacity	300 meters, 1” core
Label Roll Capacity	127 mm (5”) OD
Interface	RS-232, Centronics, USB 2.0 (Full Speed mode)
Power Supply	100 - 240 Vac, 1 Phase
Speed	Up to 1500 Labels / Min.

Expanded specification view ↓

Product details

Thermal Transfer Desktop Barcode Printer Model TTP – 345, delivers more performance for the price than any other printer in its class. The TTP-345 runs at an impressive 177.8mm per second, printing up to 4 inches wide at 203 dpi resolution. It offers USB 2.0, parallel and serial connectivity. It also incorporates the printer-control language, while supporting TPLE (Translation Printer Language Eltron®) and TPLZ (Translation Printer Language Zebra®). The languages automatically decipher and translate the format of each label as it is sent to the printer. TSPL-EZ™ also features internal scalable True Type fonts (based on the Monotype® font engine), which are typically found only in more expensive printers. It can be mounted with the below Label Winder Model LRW-100 to print Serial No., Data, Logos, Scannable Bar Codes, etc.

Specifications (13)

Media Width	20 – 112 mm (0.78” – 4.4”)
Media Thickness	0.06 – 0.19 mm (2.3 – 7.4 mil), max 150 g/m2
Media Core Diameter	25.4 – 76.2 mm (1” – 3”)
Label Length	Min. 10 mm (0.4”)
Resolution	300 dpi
Print Speed	2, 3, 4, 5 ips selectable
Maximum Print Width	106 mm (4.17”)
Maximum Print Length	1,016 mm (40”)
Ribbon Capacity	300 meters, 1” core
Label Roll Capacity	127 mm (5”) OD
Interface	RS-232, Centronics, USB 2.0 (Full Speed mode)
Power Supply	100 - 240 Vac, 1 Phase
Speed	Up to 1500 Labels / Min.
