AHLM-100

Automatic Horizontal Sticker Labeling Machine Model AHLM 100

Name: Automatic Horizontal Sticker Labeling Machine Model AHLM 100
SKU: KFT-AHLM-100
Price: 249000 INR

₹249,000

Automatic top-surface label applicator for boxes, pouches and containers, with 12-inch stainless-steel belt conveyor described. Narrative claims up to 100 items/min; table gives 0–30 pieces/min and 0–20 metres/min. Automatic feeding conveyor is optional, and variable-data printing integration is mentioned.

Confirm configuration, availability and commercial terms with our team.

Specifications

Product Size	40 mm to 500 mm
Label Roll Dia (I/O)	76mm / 320mm
Label Size (Lxw)	6 x 15 to 150 x 130 mm
Power Supply	230 Vac, 1 Phase, 0.5 HP
Speed	0 – 20 Meters/Min. or 0-30 pcs/min.
Size / Weight	L758 x W1100 x H1480 mm / 85 Kgs

Expanded specification view ↓

Product details

Fully Automatic Horizontal Sticker Labeling Machine Model AHLM – 100 for applying sticker labels in roll form from top on Boxes, Pouches, Containers, etc. at speeds up to 100 per minute with 12” Stainless Steel Belt Conveyor. Automatic feeding conveyor can be provided optionally. Online Batch / Bar Code or Inkjet printer connected to computer for variable data can be integrated to print variables like BNo, MfgDt, ExpDt, MRP, Product Name, Ingredients, Address, etc. along with Serial No. & Bar Code also available.

Specifications (6)

Product Size	40 mm to 500 mm
Label Roll Dia (I/O)	76mm / 320mm
Label Size (Lxw)	6 x 15 to 150 x 130 mm
Power Supply	230 Vac, 1 Phase, 0.5 HP
Speed	0 – 20 Meters/Min. or 0-30 pcs/min.
Size / Weight	L758 x W1100 x H1480 mm / 85 Kgs
