Map Vacuum Tray Sealer
Conveyor Type Vacuum Skin Packing and MAP Tray Sealing Model MAP 450TFV
MAP-450TFV

Conveyor Type Vacuum Skin Packing and MAP Tray Sealing Model MAP 450TFV

₹1,499,000

Conveyor four-tray machine labelled for vacuum, skin packing and mixed-gas MAP. Supplier describes eye-mark/plain-film compatibility, pneumatic operation, automatic tray/film movement, mould changes and one supplied mould set. It requires a separately procured compressor; individual packing-mode specifications and gas/mixer scope are incomplete.

Confirm configuration, availability and commercial terms with our team.

Specifications

Maximum Width Of Film450 mm
Trays To Seal140x190 mm x 4
Production Rate400 – 500 trays per hour.
Vacuum Pump63 m3 / hr
Power Consumption380V AC / 700 W
Machine Dimensions /280 X 95 X 162 cm
Weight (kg)762 Kg
Expanded specification view ↓

Product details

Conveyor Type Vacuum / Skin Packing and MAP Multiple Gas Purging Fully Automatic Rectangle Tray Sealing Machine Model MAP-450TFV (140x190 mm x 4) is a heavy duty, conveyorized and rugged built machine with Eye mark sensor / plain film sealing compatibility. Automatic tray movement, auto film rolling and auto sealing. Full Stainless Steel 304 and aluminium extrusion framed machine, Pneumatically operated machine, Easy Mould Change system, (Air compressor required 2HP, 100-200ltrs to be procured locally by you). Machine will be supplied with 1 set of mould. The containers travels automatically inside the machine where the Multiple Gases or Combination of Gases is purged into the containers, lid is cut & sealed over them from the roll & the sealed containers then comes out with automatic advancement of sealing film. This is Ideal for Supermarket delivery foods such as fresh meat, processed meat products, fish, poultry, seafood, fruits, vegetables, tea, bread, etc.

Same as above with 550mm Model MAP-550TFV (140x190 mm x 4)

Specifications (7)

Maximum Width Of Film450 mm
Trays To Seal140x190 mm x 4
Production Rate400 – 500 trays per hour.
Vacuum Pump63 m3 / hr
Power Consumption380V AC / 700 W
Machine Dimensions /280 X 95 X 162 cm
Weight (kg)762 Kg
