ELM-100

Semi Automatic Edge Security Sticker Labeling Model ELM 100

Name: Semi Automatic Edge Security Sticker Labeling Model ELM 100
SKU: KFT-ELM-100
Price: 99000 INR

₹99,000

Desktop semi-automatic applicator for right-angle security/flap-closing labels on flat boxes/cartons. Operator holds and gently pushes the box. Source lists label materials/shapes, box dimensions and 15–40 boxes/min. Ultrasonic sensing for transparent labels is an additional-cost option.

Confirm configuration, availability and commercial terms with our team.

Specifications

Product Dimensions (mm)	L: Any; W:20mm～320mm; H: 10mm～100mm
Label Size: W X L	L:10mm ～ 24mm; W:15mm ～ 45mm.
Label Material	Polyester, Polypropylene, Aluminium-foil paper, Synthetic paper
Label Shape	Circular, Oval, Rectangle, Heart-shaped
Labeling Speed	15 – 40 boxes/min
Labeling Accuracy	± 0.5mm
Roll Dia. Ext. / Int.	≤ φ120 mm / φ42 - φ75 mm
Power Supply	220V 50HZ/60HZ, 6W
Machine Size / Weight	350mm×165mm×220mm(L × W × H) / 10Kg

Expanded specification view ↓

Product details

Semi-Automatic Edge Security Sticker Labeling Model ELM – 100 for applying Security or Flap Closing Sticker labels at Right Angle on Flat boxes / cartons at speeds up to 40 per minute. Just press and hold the box and push it gently to complete the right-angle seal. This is an ideal desktop labeler. Compacted design, it is light and convenient to move. Scope of application: PP tape, PET cloth tape, Glass cloth tape, and so on. Sealing of outer casings of pharmaceuticals, cosmetics, foods, and precision parts.

Additional cost for Ultrasonic Transparent type Label sensing Sensor

Specifications (9)

Product Dimensions (mm)	L: Any; W:20mm～320mm; H: 10mm～100mm
Label Size: W X L	L:10mm ～ 24mm; W:15mm ～ 45mm.
Label Material	Polyester, Polypropylene, Aluminium-foil paper, Synthetic paper
Label Shape	Circular, Oval, Rectangle, Heart-shaped
Labeling Speed	15 – 40 boxes/min
Labeling Accuracy	± 0.5mm
Roll Dia. Ext. / Int.	≤ φ120 mm / φ42 - φ75 mm
Power Supply	220V 50HZ/60HZ, 6W
Machine Size / Weight	350mm×165mm×220mm(L × W × H) / 10Kg

Semi Automatic Edge Security Sticker Labeling Model ELM 100

Specifications

Product details

Specifications (9)
