Manual Inkjet Printers
Handheld Large Character Ink Jet Printer Model IJP 480H 72mm
IJP-480H

Handheld Large Character Ink Jet Printer Model IJP 480H 72mm

₹439,000

Portable large-character piezoelectric printer with touchscreen, grouped messages and USB/Wi-Fi/Bluetooth connectivity. A heater and handheld UV LED curing unit are listed as an additional option; heated UV ink carries a stated printhead-replacement interval.

Confirm configuration, availability and commercial terms with our team.

Specifications

Coder ModelInk Jet Printer IJP – 480H
Display5” full color Touch Screen LCD with LED backlight.
CommunicationUSB, WiFi or Bluetooth
LanguagesEnglish, Spanish, French, German, Chinese, etc.
Input Device800 x 480 Touch Screen LCD
Printable ImagesAlphanumeric, Logo, Date/Time, Counter, All standard bar codes including 2D.
Printing Area1 to 25 lines of 2000 char. each from 3 to 72 mm high.
Printing DirectionAdjustable at any angle within 360 degree
Message CapacityStore upto 100+ messages with Message Name.
Printing SpeedMax. 60 meters/min for 1 to 25 line printing at 200 dpi
Prints UsingXAAR - 384 nozzle Piezo Print-head for spraying ink
Print Distance1 ~ 10mm from substrate down or in front.
Inking Medium70 cc disposable pre-mix ink in Cartridge form.
Printing MediumSolvent/Oil/UV based inks (black, white, red, blue, etc.)
Ink Drying TimeMin. 5 to 10 seconds on plastics & laminates.
ImpressionsAppx. 50 Lakh dot-matrix characters of 2 mm per cartridge of ink.
Operating Range5 ~ +40ºC, 10% - 90% RH, non-condensing.
Supply Voltage100 ~ 260 Vac, 50/60 Hz, 15 W
Battery Voltage16.8V lithium battery, 6 hours use / 7 hours standby
DimensionsH148 × W132 × D100 mm
Weight1.6 Kg excluding cartridge & battery.
Expanded specification view ↓

Product details

Industrial Handheld Non-Contact Large Character Ink Jet Printer Model IJP – 480H (72mm), which is a Compact design, Zero Maintenance, 185 dpi high resolution, Battery Powered TWENTY line (character height 1 to 72 mm) Printer & can be used on Porous / Non-Porous products to print B.No., Exp.Date, Time, Serial No. (AGMARK), Logos, Scannable Variable Bar Codes, etc. on labels, cartons, pouches, drums, containers, etc. It is fully programmable using the 5-inch full color Touch Screen LCD with stand-alone operation (no PC required) where it can print 20 lines Data at a very low price. It is also capable of printing Multi-Segment / Grouped messages.

Additional cost for Heater & Hand Held UV Curing LED unit for above printers using UV Curable Ink which is permanent. +` 59,000/-

The system is inclusive of below mentioned accessories worth Rs. 30,000/- free of cost:

a. Hard Aluminum Carry Case with molded slots for printer & accessories.

b. 1 No. 2200 mAh Rechargeable Batteries, Charger, Computer Software.

c. 1 No. disposable Pre-mix ink cartridge, 1 No. Cleaning Cartridge.

d. Operator Tool Kit, Touch Pen, Operation & Maintenance Manual, Instruction Video.

This printer is fully Electronic without CORE system & does not have any air pump, viscosity control unit, filters, etc. & so there is no maintenance required (No AMC). It does not require separate make up or wash solution as everything is included in the disposable ink cartridges making it very user friendly for the Operator. The running / Printing cost is only about 4 Paise per impression (25 char). Due to the heated UV Inks used, the Printhead might need to be replaced every 6 months to 2 years.

Specifications (21)

Coder ModelInk Jet Printer IJP – 480H
Display5” full color Touch Screen LCD with LED backlight.
CommunicationUSB, WiFi or Bluetooth
LanguagesEnglish, Spanish, French, German, Chinese, etc.
Input Device800 x 480 Touch Screen LCD
Printable ImagesAlphanumeric, Logo, Date/Time, Counter, All standard bar codes including 2D.
Printing Area1 to 25 lines of 2000 char. each from 3 to 72 mm high.
Printing DirectionAdjustable at any angle within 360 degree
Message CapacityStore upto 100+ messages with Message Name.
Printing SpeedMax. 60 meters/min for 1 to 25 line printing at 200 dpi
Prints UsingXAAR - 384 nozzle Piezo Print-head for spraying ink
Print Distance1 ~ 10mm from substrate down or in front.
Inking Medium70 cc disposable pre-mix ink in Cartridge form.
Printing MediumSolvent/Oil/UV based inks (black, white, red, blue, etc.)
Ink Drying TimeMin. 5 to 10 seconds on plastics & laminates.
ImpressionsAppx. 50 Lakh dot-matrix characters of 2 mm per cartridge of ink.
Operating Range5 ~ +40ºC, 10% - 90% RH, non-condensing.
Supply Voltage100 ~ 260 Vac, 50/60 Hz, 15 W
Battery Voltage16.8V lithium battery, 6 hours use / 7 hours standby
DimensionsH148 × W132 × D100 mm
Weight1.6 Kg excluding cartridge & battery.
