Smart Thermal Transfer Overprinter Model TTO W50 Plus 53mm
TTO-W50+

Smart Thermal Transfer Overprinter Model TTO W50 Plus 53mm

₹329,000

Touchscreen thermal-transfer overprinter with a 53 mm head and separately listed intermittent/continuous modes. Variable information and barcode formats are listed; the external data interface/protocol is not specified.

Confirm configuration, availability and commercial terms with our team.

Specifications

Touch Screen7 inch Full Colour
Printing ModesIntermittent (Static) & Continuous* (Online*) Modes separately.
Print Density53mm, 300 dpi
Print Speedintermittent 2m/min-30m/min, continuous 0.5m/min – 42m/min
Printing Frequencyintermittent max250 times/min, continuous max370 times/min
Print Area53*90mm intermittent ,53*150mm continuous
Maximum. Ribbon Length600m (Wax/Resin, Premium Wax/Resin, Resin, Ultra Resin)
Ribbon Width33-55mm (Ink outside)
Ribbon Saving FeaturesCan save up to 60% ribbon usage
Coding Direction0º to 180º
Applicable PrintingCan print date, time, series number, variable info, barcode, photo, etc.
Barcode / Qr CodeCode128(GS1), EANX, Code11, QR Code, UPCA, UPCE, etc.
Working Pressure0.6Mpa (maximum), dry, pollution-free
External InputSensor Input Signal: NPN/PNP (DC 12-24V), switch-type sensor
Operating Range5ºC ~ 40ºC, 10% - 90% RH, non-condensing.
IP ClassIP40
Dimensions (W×H×D)Controller size:220*120*30 mm, Print unit:210*180*190 mm
Weight8kg / 0.75Kg
Power Supply100 – 240 VAC, 50/60Hz, 200W
Expanded specification view ↓

Product details

Industrial Advanced Smart Thermal Transfer Overprinter Model TTO-W50+ (53mm) is an enhanced smart product designed for the upgrade of traditional TTO using Japanese Kyocera 53mm printing head. In addition to using it to print of Production Date, shelf life, series number, batch number, time, etc., you can also print any 1D code, 2D code, product traceability code, logo, graphics and other content as needed. It can integrate seamlessly into a range of flexible packaging machines & can print clear legible alpha numeric, logo, barcode as well as text on both intermittent and high-speed production lines.

Easy & quick installation, can directly replace the traditional Coding Machines.

Touch Screen controls the Settings & Coding matter, so there is no need for cumbersome operations (such as typesetting), except the replacement of ribbon.

Stable printing quality without puncture of packaging material & smudged printing.

Intelligent control of ribbon operation maximizes ribbon use & not allows it to run empty.

Coding Time and Batch Number can be updated automatically to avoid human errors, misprint and omissions.

Start immediately without heating with clear printing at Low print cost & high speeds.

Able to freely edit 1D code, 2D code, serial number, characters, numbers, punctuation, etc. in the printing area along with LOGOs. & Graphics.

Specifications (19)

Touch Screen7 inch Full Colour
Printing ModesIntermittent (Static) & Continuous* (Online*) Modes separately.
Print Density53mm, 300 dpi
Print Speedintermittent 2m/min-30m/min, continuous 0.5m/min – 42m/min
Printing Frequencyintermittent max250 times/min, continuous max370 times/min
Print Area53*90mm intermittent ,53*150mm continuous
Maximum. Ribbon Length600m (Wax/Resin, Premium Wax/Resin, Resin, Ultra Resin)
Ribbon Width33-55mm (Ink outside)
Ribbon Saving FeaturesCan save up to 60% ribbon usage
Coding Direction0º to 180º
Applicable PrintingCan print date, time, series number, variable info, barcode, photo, etc.
Barcode / Qr CodeCode128(GS1), EANX, Code11, QR Code, UPCA, UPCE, etc.
Working Pressure0.6Mpa (maximum), dry, pollution-free
External InputSensor Input Signal: NPN/PNP (DC 12-24V), switch-type sensor
Operating Range5ºC ~ 40ºC, 10% - 90% RH, non-condensing.
IP ClassIP40
Dimensions (W×H×D)Controller size:220*120*30 mm, Print unit:210*180*190 mm
Weight8kg / 0.75Kg
Power Supply100 – 240 VAC, 50/60Hz, 200W
