AVLM-100-FLAT

Automatic Sticker Labeling Machine Model AVLM 100 Flat

Name: Automatic Sticker Labeling Machine Model AVLM 100 Flat
SKU: KFT-AVLM-100-FLAT
Price: 349000 INR

₹349,000

Automatic roll-label applicator for flat bottles, with top clamp-down conveyor for stability. Supplier also mentions square and oval bottles with unexplained asterisks. Narrative/table claim up to 80 containers/min. Variable-data printing integration and 750 W servo variant are separately mentioned.

Confirm configuration, availability and commercial terms with our team.

Specifications

Size Of Container	30 mm to 100 mm
Height Of Container	35 mm to 270 mm
Label Width	25 x 25 to 100 x 300 mm, Gap 3mm minimum.
Label Roll Dia	Max. OD 280mm, ID 76mm
Power Supply	230 Vac, 1 Phase, 0.5 HP
Speed	Up to 80 Cont. / Min.
Accuracy	±1.5 mm

Expanded specification view ↓

Product details

Fully Automatic Sticker Labeling Machine Model AVLM – 100 – Flat for applying sticker labels in roll form on flat (also square* & oval*) bottles at speeds up to 80 bottles per minute along with Clamp Down Conveyor on top of bottles to provide stability. The Machine incorporates latest sophisticated Micro Processor Control Label Dispensing system with user friendly Sensing system for Label and Product. Online Batch / Bar Code or Inkjet printer connected to computer for variable data can be integrated to print variables like BNo, MfgDt, ExpDt, MRP, Product Name, Ingredients, Address, etc. along with Serial No. & Bar Code also available.

Same as above with 750W Servo system Model AVLM – 100-Flat-S

Specifications (7)

Size Of Container	30 mm to 100 mm
Height Of Container	35 mm to 270 mm
Label Width	25 x 25 to 100 x 300 mm, Gap 3mm minimum.
Label Roll Dia	Max. OD 280mm, ID 76mm
Power Supply	230 Vac, 1 Phase, 0.5 HP
Speed	Up to 80 Cont. / Min.
Accuracy	±1.5 mm

Automatic Sticker Labeling Machine Model AVLM 100 Flat

Specifications

Product details

Specifications (7)
