Form Fill Seal Machine
Counting Type Tablets and Pellets Packing FFS Machine Model FFS 100C 200mm
FFS-100C

Counting Type Tablets and Pellets Packing FFS Machine Model FFS 100C 200mm

₹149,000

Automatic piece-counting form-fill-seal pouch packer for tablets, capsules, pellets, buttons and other dry objects. Source states 1–10,000 pieces per pack, but accuracy and speed conditions use generic weight/flow wording. Counting method, piece rate and validated counting accuracy remain unresolved.

Confirm configuration, availability and commercial terms with our team.

Specifications

DescriptionDETAILS
SealingCenter Seal (Optional 3 SIDE seal)
Pouch Size0-100 MM (W) and 0-150 MM (L) HEIGHT
RangeFor 01 to 10000 pieces
Output (pouches/min)10 to 18 ppm, depending upon product characteristics, fill weight, bulk density of the product, it’s flow properties. It also depends upon the kind, quality and thickness of laminate being used.
Packaging MaterialAny heat sealing films (laminates) 0.5mm to 0.8mm
DriveSINGLE PHASE MOTOR
Registration SystemOptional Photocell control using optical scanning head sensor & control unit to drive 1/8 HP forward reverse correction motors.
Contact PartsPRODUCT CONTACT PARTS SS 304 BODY WILL BE COVERED WITH SS 304 DRIVE ROLLER SHAFT MS EN8 SEALING JAW MS EN8
Accuracy+/- 2% Actual fill depend upon type of product and consistency in its flow characteristics.
Roll DiameterMaximum 14 inches.
Core Inner Diameter76 MM ID.
Net Wt.70 Kg. approximately.
MountingOn wheels.
Overall Dimensions430 mm(L) x 510(W) mm x 1400 mm(H)
Expanded specification view ↓

Product details

Automatic Counting Type Tablets / Pellets Packing FFS Machine Model FFS-100C (200mm) are ideal for Counting & Packing in Pouches of Tablets, Capsules, Pellets, Buttons, etc. Machines that form the package, fill it with a dry product, and seal it shut are known as Form-Fill-Seal machines. Flexible film is used in most FFS packing machine to create the primary kit, such as a bag or pouch. These machines ensure hygienic packing of the product along with the focus on keeping moisture away from the product for retaining the free flow texture of the same. The introduction of digital control particle filling machines in advanced technology in many industries has increased work efficiency. These machines often feature intermediate perforation for consecutive pouches, as well as the ability to cut strips after a predetermined number of pouches using a digital auto–cut feature. This is useful for filling of all types of oblects in Bottles, Jars & Glasses.

Features

Rapid modification of the bag specifications.

Modular heating, more precise temperature control.

The CAM design of the single shaft

Clean and no wastage

Leak-proof sealing

Irregular particle materials, ≤ 2cm of diameter, and the length ≤ 3cm such as: All kinds of beans, Wheat, corn, Dog and cat foods, Candies, Buttons, beads, etc.

Very long lifetime due to durable designing

Low maintenance efforts

We provide Granule Filling Machines with PLC control bag length regulation. It can be used with heat-sealable compound materials, including single paper/PE, cellophane/PE, aluminium foil/PE, BOPP/PE, Nylon/PE, and so on. The inside wall has a screw structure to quickly and stably enhance the vibration of the feeding stuff. It's driven by a microcomputer. The entire machine has a stainless steel shell, buckle design.

Same machine as above with Double Feeder Model FFS-100CD (200mm)

Same machine as above with 240mm roll Model FFS-100CL (240mm)

Extra Chute / Former of any size

LD + Polyster Plain Transparent Roll of 75GSM (Per Kg)

Specifications (15)

DescriptionDETAILS
SealingCenter Seal (Optional 3 SIDE seal)
Pouch Size0-100 MM (W) and 0-150 MM (L) HEIGHT
RangeFor 01 to 10000 pieces
Output (pouches/min)10 to 18 ppm, depending upon product characteristics, fill weight, bulk density of the product, it’s flow properties. It also depends upon the kind, quality and thickness of laminate being used.
Packaging MaterialAny heat sealing films (laminates) 0.5mm to 0.8mm
DriveSINGLE PHASE MOTOR
Registration SystemOptional Photocell control using optical scanning head sensor & control unit to drive 1/8 HP forward reverse correction motors.
Contact PartsPRODUCT CONTACT PARTS SS 304 BODY WILL BE COVERED WITH SS 304 DRIVE ROLLER SHAFT MS EN8 SEALING JAW MS EN8
Accuracy+/- 2% Actual fill depend upon type of product and consistency in its flow characteristics.
Roll DiameterMaximum 14 inches.
Core Inner Diameter76 MM ID.
Net Wt.70 Kg. approximately.
MountingOn wheels.
Overall Dimensions430 mm(L) x 510(W) mm x 1400 mm(H)
