AMS-100TD

mAP Double Rectangle Tray Sealing Machine Model AMS 100TD 140 x 190 mm

Name: mAP Double Rectangle Tray Sealing Machine Model AMS 100TD 140 x 190 mm
SKU: KFT-AMS-100TD
Price: 399000 INR

₹399,000

Pneumatically operated double rectangular tray sealer, 140×190 mm designation, with automatic tray movement, film feed and sealing, eye-mark/plain-film compatibility and mould changes. SS304/aluminium frame and one supplied mould set are described. Body identifies AMS-100TD; gas-purging MAP is separately named AMS-100TDM despite the MAP page title.

Confirm configuration, availability and commercial terms with our team.

Specifications

Production Rate	8 – 12 trays per Minute.
Power Consumption	220V AC / 15 Amps
Machine Dimensions / Weight	480 X 705 X 820 mm / 90 Kg

Expanded specification view ↓

Product details

Fully Automatic Double Rectangle Tray Sealing Machine Model AMS-100TD (140 x 190 mm) is a heavy duty and rugged built machine with Eye mark sensor / plain film sealing compatibility. Automatic tray movement, auto film rolling and auto sealing. Stainless steel 304 and aluminium extrusion framed machine, Pneumatically operated machine, Easy Mould Change system, (Air compressor required 2HP, 100-200ltrs to be procured locally by you). Machine will be supplied with 1 set of mould. The container automatically travels inside the machine where the lid is cut & sealed over it from the roll & the sealed container then comes out with automatic advancement of sealing film. This is Ideal for Mineral Water, Shrikhand, Carry-Out Bowl products, Soups, Sweets & Hotel Lunch Packing of Glasses, trays, etc.

Same as above with MAP Model AMS-100TDM for Automatic Gas Purging

Specifications (3)

Production Rate	8 – 12 trays per Minute.
Power Consumption	220V AC / 15 Amps
Machine Dimensions / Weight	480 X 705 X 820 mm / 90 Kg
