MDM-100A

Fully Automatic Analog Metal Detector Machine Model MDM 100A

Name: Fully Automatic Analog Metal Detector Machine Model MDM 100A
SKU: KFT-MDM-100A
Price: 319000 INR

₹319,000

Analog conveyor metal detector using balance-coil/phase-shift technology. Supplier lists ferrous/non-ferrous/stainless sensitivity and a 150×80 mm usable opening inside a 200×100 mm aperture. Base rejection is belt stop with siren; pneumatic air-jet rejection is optional. Digital controls are a separately mentioned MDM-100D variant.

Confirm configuration, availability and commercial terms with our team.

Specifications

Detection Technology	Electromagnetic Balance Coil (Phase Shift Technology)
Aperture Size	200mm Wide X 100 mm Height
Usable Clear Size	150mm W X 80mm H
Metal Partials Sensitivity	ᴓ0.8mm Ferrous, ᴓ1.0mm Non-Ferrous, ᴓ1.2mm Stainless Steel In all Metal mode
Detector Coil Used	Imported (German)
Conveyor Belt Type	PU Food Grade, 2.0 mm thickness, 22 Meters / Min
Construction	Stainless Steel (304 Grade) Smooth Dull Finish
Rejection Type	Belt Stop with Siren, Optional Pneumatically Operated Air Jet Rejection System with audio visual alarm
On Board Display	For Analog Version: LED Bar Graph, Power ON, Metal Trip, Reject, Bypass, Buzzer, Reset Push Button.
Conveyor Dimensions	1.5 Mtrs. Long X 0.5 Mtrs. Width X 0.75 Mtrs. Height.
Conveyor Motor	BONFIGILIOLI Make Geared Motor (Flange Mounted)
IP Rating	IP 65 (Dust + Water Resistant + Non-Corrosive)
Power Supply	230 Vac, 1 Ph, 0.5 HP / 415Vac, 3Ph, 50Hz conveyor
Machine Dimensions**	1500 mm (L) x 610 mm (W) x 1200 (H) Approx.
Net Weight	70 Kgs. Approx.
Documents Included	Comprehensive Manual; IQ, OQ, PQ Documents with Validation Certifications; Wire Diagram; Calibration and Test Certificates; MOC Certificate; Warranty Certificate; Certifications and Compliances Copies for Traceability.

Expanded specification view ↓

Product details

Fully Automatic Analog Metal Detector Machine Model MDM – 100A Conveyorized Metal Detector having an Aperture size of 200 mm Width and 100 mm Height, designed to detect metal contamination of 0.8 mm Ferrous, 1.0 mm Non-Ferrous 1.2 mm Metals & above. The material or packages to be inspected will pass through the Detector’s aperture where it creates a high frequency electromagnetic field. Presence of foreign metallic particles causes a reaction in this field, which is sensed by the Detector, and the signal is amplified as required. The signal output is in the form of relay contacts which can be used to stop a conveyor, sound an alarm, and actuate a marking system or any other device or combination of devices.

Same machine as above with Digital Controls Model MDM – 100D

Kindly watch Demo Video: https://youtu.be/vImryTJE5eY Download Catalog

Specifications (16)

Detection Technology	Electromagnetic Balance Coil (Phase Shift Technology)
Aperture Size	200mm Wide X 100 mm Height
Usable Clear Size	150mm W X 80mm H
Metal Partials Sensitivity	ᴓ0.8mm Ferrous, ᴓ1.0mm Non-Ferrous, ᴓ1.2mm Stainless Steel In all Metal mode
Detector Coil Used	Imported (German)
Conveyor Belt Type	PU Food Grade, 2.0 mm thickness, 22 Meters / Min
Construction	Stainless Steel (304 Grade) Smooth Dull Finish
Rejection Type	Belt Stop with Siren, Optional Pneumatically Operated Air Jet Rejection System with audio visual alarm
On Board Display	For Analog Version: LED Bar Graph, Power ON, Metal Trip, Reject, Bypass, Buzzer, Reset Push Button.
Conveyor Dimensions	1.5 Mtrs. Long X 0.5 Mtrs. Width X 0.75 Mtrs. Height.
Conveyor Motor	BONFIGILIOLI Make Geared Motor (Flange Mounted)
IP Rating	IP 65 (Dust + Water Resistant + Non-Corrosive)
Power Supply	230 Vac, 1 Ph, 0.5 HP / 415Vac, 3Ph, 50Hz conveyor
Machine Dimensions**	1500 mm (L) x 610 mm (W) x 1200 (H) Approx.
Net Weight	70 Kgs. Approx.
Documents Included	Comprehensive Manual; IQ, OQ, PQ Documents with Validation Certifications; Wire Diagram; Calibration and Test Certificates; MOC Certificate; Warranty Certificate; Certifications and Compliances Copies for Traceability.
